backed up data. After a few seconds the machine will beep once and the
Initialising screen will be displayed before the machine returns to standby
mode, ready to vend.
7.6.5 Software Version
The Software version menu displays the version number of the software
installed and is for information only. The menu also displays the current time
and date.
7.6.6 I/O Board Software
This menu displays the version number of the I/O board software installed and
is for information only.
7.6.7 Temperature Units
This menu allows the operator to change the
way that the temperature is displayed, either
°C or °F, on the LCD when the machine is in
standby mode. Use the ▲ (up) or ▼ (down)
keys to set the required option followed by the
↵ (Edit) key to store/save it (indicated by the
filled radio button).
7.6.8 Idle Screen Options
This menu allows the operator to configure the LCD so that it displays either
the time or the time and water temperature with the standby message when
idle. To configure the idle screen options, proceed as follows:
1. From the System Settings menu press the
▼ (down) key to highlight Idle Screen
Options and press the ↵ (Edit) key to
access the menu.
2. Press the
▼ (down) key to highlight the
required option, eg Time and Temp
(indicated by the filled radio button). The
LCD will display the screen as shown
opposite. Press the ↵ (Edit) key to return
to the System Settings screen. With Idle
Screen Options highlighted, verify that the
status line confirms the option is set to
Time and Temp.
3. Press the X (Exit) key until the machine exits the engineers program into
standby mode. The LCD will display the standby message with the time
and date as shown.
51
