28 Genie DPL Super Series Part No. 82799
Operator’s Manual Second Edition • First Printing
Specifications
Model DPL-25S DPL-30S DPL-35S
Height, 31 ft 4 in 36 ft 40 ft 9 in
maximum working 9.5 m 11 m 12.4 m
Height, 25 ft 4 in 30 ft 34 ft 9 in
maximum platform 7.7 m 9.1 m 10.6 m
Height, 78 in 78 in 78 in
guard rails stowed 1.98 m 1.98 m 1.98 m
Length, 81
3
/4 in 81
3
/4 in 81
3
/4 in
outriggers stowed 2.07 m 2.07 m 2.07 m
Width, 31
1
/2 in 31
1
/2 in 31
1
/2 in
outriggers stowed 80 cm 80 cm 80 cm
Outrigger footprint 84 x 60 in 89 x 73 in 89 x 73 in
(l x w) 2.1 x 1.5 m 2.3 x 1.9 m 2.3 x 1.9 m
Platform dimensions 72 x 27
1
/2 in 72 x 27
1
/2 in 72 x 27
1
/2 in
(l x w) 1.83 m x 69.9 cm 1.83 m x 69.9 cm 1.83 m x 69.9 cm
Power source
AC 220V or 115V 220V or 115V 220V or 115V
DC 12V 12V 12V
Air power 100 psi / 6.9 bar @ 100 psi / 6.9 bar @ 100 psi / 6.9 bar @
80 cfm / 2.26 m
3
/min 80 cfm / 2.26 m
3
/min 80 cfm / 2.26 m
3
/min
Weight See Serial Plate See Serial Plate See Serial Plate
(Machine weights vary with option configurations)
Maximum capacity
ANSI 750 lbs / 340 kg 750 lbs / 340 kg 600 lbs / 272 kg
CE 750 lbs / 340 kg 750 lbs / 340 kg 600 lbs / 272 kg
CSA 600 lbs / 272 kg 600 lbs / 272 kg 500 lbs / 227 kg
Ambient operating -20°F to 135°F
temperature -29°C to 57°C
Airborne noise emissions 80 dB
Maximum sound level at normal operating workstations
(A-weighted)
Wheel load, maximum 419 lbs 190 kg
Outrigger load, maximum 581 lbs 264 kg
Continuous improvement of our products is a
Genie policy. Product specifications are subject
to change without notice or obligation.
