Check for wood garage frame, jamb, or masonry at mounting location
(6" above floor) with attachment tabs facing away from garage door
(Figure 7).
A
If you cannot mount Safe-T-Beam@Mounting Bracket to
wood frame:
. Concrete screws and concrete anchors (not included)
must be used to mount Brackets on masonry with
attachment tabs facing away from garage door.
. Safe-T-Beam@Mounting Bracket Extensions may be used
(not included - available from a Genie Factory Authorized
Dealer or through Accessories Order Form on pages 31/32).
_ _60_5 M I]IUb Eb TOOLS
A
B
Tools (Figure 8):
Additional tools to make installation easier:
• Slotted and phillips screw-driver bits
• Stud finder
• Sheet-metal cutting snips
Source I
Sensor
Safe T Beam @ ,i,l,,ll/ll_
Mounting Bracket
; // I _" Bracket 6"
#,_ I above
_ 41_r7 I floor
Figure 7 Mounting Safe-T-Beam @Components
IillT;40vE EXI_;_ll_G 6ABA_[I£
Check that the garage door locks, rope, and T-Handles are removed
from the garage door before starting the installation.
A If your garage does not have a separate entry door, it ishighly
recommended to install a Genie Emergency Release Kit (GER-2).
Emergency Release Kit lets you open garage door from outside if
there is a power failure. (Please see Accessories Order Form on
pages 31/32.)
Befo_,4_-9o __9f_x_t_"_e_,9<_t a_,_yterns a_,'_dtoo
_,s®®d®do 7'os_
[] Safe-T-Beam @Sensor Mounting Bracket Extensions (dealer)
[] Garage door opener reinforcement bracket (dealer)
[] Garage door frame reinforcement brackets, screws, bracing
or reinforcement kits (dealer)
[] Lag Screws (11/4") for a wood door less than 2" thick (store)
[] Electrical outlet and/or wiring (supplied by a
licensed electrician)
[] Excelerator Extension Kit (for 8' garage doors) (store)
[] Sufficient angle iron or strapping for hanging Power Head
(store)
[] Two 60Watt light bulbs
(Rough service bulbs recommended)(store)
[] GER-2 Emergency Release Kit for entry during power failure
(store)
[] Wood for header, ceiling, and/or door bracing reinforcement
(if needed)
[] Masonry fasteners for Safe-T-Beam @Bracket installation,
(if needed)
[] Masonry drill bit (if needed)
Drill
1/16" 5/32"
Drill Bit Drill Bit
6' or 7'
Step Ladde_
Adjustable Wrench
Phillips Screwdriver
Hack Saw
12' *
Tape
Hammer
Wire
Stripper
Safety Glasses
(1i¢ ">
Pencil
888888
1/4" 5/16" 3/8" 7/16" 1/2" 9/16"
Sockets
Carpenter's Level
Figure 8 Recommended Tools
