Genie ZX-135/70 with Jib-Extend User Manual

Operator's Manual Third Edition • First Printing
ZX-135/70 Part No. 1272823GT
Front Matter
Contents
Introduction ........................................................... 1
Symbol and Hazard Pictorials Definitions ............. 4
General Safety ...................................................... 6
Personal Safety ..................................................... 9
Work Area Safety ................................................ 10
Legend ................................................................ 18
Controls ............................................................... 19
Inspections .......................................................... 28
Operating Instructions ......................................... 46
Transport and Lifting Instructions ....................... 55
Maintenance ....................................................... 58
Specifications ...................................................... 61
Copyright © 2011 by Terex Corporation
Third Edition: First Printing, March 2017
Genie and "ZX" are registered trademarks of
Terex South Dakota, Inc. in the U.S.A. and many
other countries.
Complies with EC Directive 2006/42/EC
See EC Declaration of Conformity

Genie ZX-135/70 with Jib-Extend Specifications

General

Turntable Rotation	360° continuous
Platform Rotation	160°
Gradeability	45%
Maximum Platform Height	135 ft
Engine Power	74 hp
Fuel Type	Diesel
Stowed Height (ft)	10 ft
Max Working Height	141 ft
Platform Height	135 ft
Max Horizontal Reach	70 ft
Platform Capacity	600 lbs
Machine Width	8 ft 2 in
Stowed Height	10 ft
Drive Speed - Stowed	3.5 km/h
Jib Length	12 ft
Horizontal Reach	70 ft
Platform Capacity (lbs)	600 lbs
Drive Speed	3.5 km/h
Stowed Length	43 ft 2 in / 13.16 m
Stowed Width	8 ft 2 in
