Operator's Manual Third Edition • First Printing
Symbol and Hazard Pictorials Definitions
4 ZX-135/70 Part No. 1272823GT
Symbol and Hazard Pic torials Definiti ons
Crush hazard
Keep away from
moving parts
Crush hazard Overhead obstruction Collision hazard
Electrocution hazard
Maintain required
clearance
Tip-over hazard Tip-over hazard Tip-over hazard
Electrocution hazard Avoid contact Disconnect battery
Read the operator’s
manual
Read the service
manual
Explosion hazard
No smoking.
No flame.
Stop engine.
Explosion hazard Burn hazard Fire extinguisher
Fire hazard No smoking Explosion hazard No step
Lanyard anchorage
points

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Genie ZX-135/70 with Jib-Extend and is the answer not in the manual?

Genie ZX-135/70 with Jib-Extend Specifications

General IconGeneral
Turntable Rotation360° continuous
Platform Rotation160°
Gradeability45%
Maximum Platform Height135 ft
Engine Power74 hp
Fuel TypeDiesel
Stowed Height (ft)10 ft
Max Working Height141 ft
Platform Height135 ft
Max Horizontal Reach70 ft
Platform Capacity600 lbs
Machine Width8 ft 2 in
Stowed Height10 ft
Drive Speed - Stowed3.5 km/h
Jib Length12 ft
Horizontal Reach70 ft
Platform Capacity (lbs)600 lbs
Drive Speed3.5 km/h
Stowed Length43 ft 2 in / 13.16 m
Stowed Width8 ft 2 in
