Operator's Manual Third Edition • First Printing
Legend
18 ZX-135/70 Part No. 1272823GT
Legend
1 Square-end tire
2 Ground controls
3 Secondary boom
4 Primary boom
5 Jib boom
6 Platform
7 Platform controls
8 Sliding mid-rail
9 Manual storage container
10 Lanyard anchorage points
11 Foot switch
