Third Edition • First Printing Operator's Manual
Specifications
Part No. 1272823GT ZX-135/70 61
Specificati ons
Model
ZX-135/70
Height, working maximum 43.15 m
Height, platform maximum 41.15 m
Height, stowed maximum 3.1 m
Horizontal reach, maximum 21.3 m
Width, axles retracted 2.5 m
Width, axles extended 5.03 m
Length, stowed 12.9 m
Maximum load capacity 272 kg
Maximum wind speed 12.5 m/s
Wheelbase, axles extended 4.72 m
Wheelbase, axles retracted 5.03 m
Ground clearance 38 cm
Turning radius, axles extended
Inside 2.9 m
Outside 6.17 m
Turning radius, axles retracted
Inside 8.03 m
Outside 9.96 m
Turntable rotation (degrees) 360° continuous
Turntable tailswing,
secondary boom lowered
4.3 m
Turntable tailswing,
secondary boom raised
0.81 m
Controls 12V DC proportional
Platform dimensions, 1.8 m
(length x width)
183 x 76 cm
Platform dimensions, 2.4 m
(length x width)
244 x 91 cm
Platform leveling self-leveling
Platform rotation 160°
AC outlet in platform Standard
Fuel tank capacity 151 liters
Hydraulic pressure, maximum
(boom functions)
203 bar
Hydraulic pressure, maximum
(auxiliary power unit)
218 bar
System voltage 12V
Tire size 445/65 D22.5
or 445D50/710, 18 ply FF
Weight 21,092 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Airborne noise emissions
Sound pressure level at ground workstation <85 dBA
Sound pressure level at platform workstation <74 dBA
Guaranteed sound power level <107 dBA
Total vibration value to which the hand/arm system is
subjected does not exceed 2.5 m/s
2
.
Highest root mean square value of weighted acceleration
to which the whole body is subjected does not exceed
0.5 m/s
2
.
Maximum slope rating, stowed position, 4WD
Counterweight uphill 45% 24°
Counterweight downhill 30% 17°
Side slope 25% 14°
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Drive speeds
Drive speed, stowed 4.8 km/h
12.2 m/9.1 sec
Drive speed, raised or extended 1.1 km/h
12.2m/40 sec
Drive speed, raised and extended 0.6 km/h
12.2 m/68 sec
Floor loading information
Tire load maximum 12,360 kg
Tire contact pressure 9.13 kg/cm
2
896 kPa
Occupied floor pressure 1,019 kg/m
2
9.99 kPa
Note: Floor loading information is approximate and does
not incorporate different option configurations. It should
be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
