Operator's Manual Third Edition • First Printing
Controls
20 ZX-135/70 Part No. 1272823GT
Ground Control Panel
1 Turntable rotate right button
Press the turntable rotate right button and the
turntable will rotate right.
2 Turntable rotate left button
Press the turntable rotate left button and the
turntable will rotate left.
3 Secondary boom up/extend and down/retract
buttons
Push the secondary boom up/extend button
and the secondary boom will raise and then
extend. Push the secondary boom
down/retract button and the secondary boom
will retract and then lower.
4 Primary boom up/down buttons
Press the primary boom up button and the
boom will raise. Press the primary boom down
button and the boom will lower.
5 LCD screen control buttons
6 Engine speed select button
Press the engine speed select button to select
the engine speed. When the arrow above the
rabbit is lit, the engine is in high idle speed.
When the arrow above the turtle is lit, the
engine is in low idle speed.
7 LCD readout screen
a low fuel indicator
b engine oil pressure indicator
c water temperature indicator
d emergency power indicator
e high engine rpm indicator
f hour meter
8 Red Emergency Stop button
Push in the red Emergency Stop button to the
off position to stop all functions and turn the
engine off. Pull out the red Emergency Stop
button to the on position to operate the
machine.
9 Glow plug button (if equipped with manual glow
plugs)
Push the glow plug button and hold for 3 to
5 seconds.
10 Key switch for off/ground/platform selection
Turn the key switch to the off position and the
machine will be off. Turn the key switch to the
ground position and the ground controls will
operate. Turn the key switch to the platform
position and the platform controls will operate.
11 Engine start button
Press the engine start button to start the
engine.
abc de
f
