Genie ZX-135/70 with Jib-Extend User Manual

Third Edition • First Printing Operator's Manual
Inspections
Part No. 1272823GT ZX-135/70 29
Pre-operation Inspection
 Be sure that the operator’s, safety and
responsibilities manuals are complete, legible
and in the storage container located in the
platform.
 Be sure that all decals are legible and in place.
See Inspections section.
 Check for hydraulic oil leaks and proper oil
level. Add oil if needed. See Maintenance
section.
 Check for battery fluid leaks and proper fluid
level. Add distilled water if needed. See
Maintenance section.
 Check for engine oil leaks and proper oil level.
Add oil if needed. See Maintenance section.
 Check for engine coolant leaks and proper
level of coolant. Add coolant if needed. See
Maintenance section.
Check the following components or areas for
damage, improperly installed or missing parts and
unauthorized modifications:
 Electrical components, wiring and
electrical cables
 Hydraulic hoses, fittings, cylinders and
manifolds
 Fuel and hydraulic tanks
 Drive and turntable motors and drive hubs
 Wear pads
 Tires and wheels
 Engine and related components
 Limit switches and horn
 Rotation sensors
 Platform load cell
 Steer and axle sensors
 Alarms and beacons (if equipped)
 Nuts, bolts and other fasteners
 Platform entry mid-rail or gate
 Lanyard anchorage points
Check entire machine for:
 Cracks in welds or structural components
 Dents or damage to machine
 Excessive rust, corrosion or oxidation
 Be sure that all structural and other critical
components are present and all associated
fasteners and pins are in place and properly
tightened.
 After you complete your inspection, be sure
that all compartment covers are in place and
latched.

Genie ZX-135/70 with Jib-Extend Specifications

General

Turntable Rotation	360° continuous
Platform Rotation	160°
Gradeability	45%
Maximum Platform Height	135 ft
Engine Power	74 hp
Fuel Type	Diesel
Stowed Height (ft)	10 ft
Max Working Height	141 ft
Platform Height	135 ft
Max Horizontal Reach	70 ft
Platform Capacity	600 lbs
Machine Width	8 ft 2 in
Stowed Height	10 ft
Drive Speed - Stowed	3.5 km/h
Jib Length	12 ft
Horizontal Reach	70 ft
Platform Capacity (lbs)	600 lbs
Drive Speed	3.5 km/h
Stowed Length	43 ft 2 in / 13.16 m
Stowed Width	8 ft 2 in
