Specifications: Bullet Camera

(Part 1)

This section details the specifications on GV-BL120D / 130D / 220D / 320D

and GV-BL1500 / 2400 / 2500 / 3400.

Camera

GV-BL120D 1/3" progressive scan low lux CMOS

GV-BL130D

GV-BL220D

GV-BL320D

1/2.5’’ progressive scan CMOS

GV-BL1500

1/3’’ progressive scan super low lux

CMOS

GV-BL2500

1/2.8’’ progressive scan super low lux

CMOS

Image Sensor

GV-BL2400

GV-BL3400

1/3.2’’ progressive scan CMOS

GV-BL120D

GV-BL130D

GV-BL1500

1280 (H) x 1024 (V)


Elements

GV-BL220D

GV-BL2400

GV-BL2500

1920 (H) x 1080 (V)

Default Chapter4
- Preface4
- Table of Contents12
- Naming and Definition24
- Device Description25
- Options25
- Note for Connecting to GV-System28
- Note for Recording29
- Note for Adjusting Focus and Zoom30
- Note for Installing Camera Outdoor31
- Note for Closing the Bullet Camera Cover33
- Note for USB Storage and Wifi Adapter34
Chapter 1 Introduction35
- System Requirement35
Chapter 2 Box Camera36
- Specifications38
- Packing List41
- Features42
  - Wide Dynamic Range Pro44
- Overview45
  - GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D45
  - GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series47
- Connecting the Camera49
- I/O Terminal Block55
  - Pin Assignment55
  - Connecting to GV-Relay V2 (Optional)56
Chapter 3 Ultra Box Camera57
- Packing List58
- Features59
- Overview60
- Installation61
- Connecting the Camera63
Chapter 4 Target Box Camera64
- Packing List64
- Features65
- Overview66
- Installation67
- Connecting the Camera69
Chapter 5 IR Arctic Box Camera70
- Packing List72
- Features74
- Overview76
- Notice for Using the IR Arctic Box Camera89
  - Enabling IR LED after Loading Default90
  - Disabling Status LED under Low Light Conditions91
Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome92
- Packing List95
- Features96
  - Gv-Mfd120 / 130 / 32096
- Overview99
- Installation106
  - GV-MFD Series106
  - GV-MDR Series108
- Connecting the Camera113
Chapter 7 Target Mini Fixed Dome116
- Packing List116
- Features117
- Overview118
- Installation119
- Connecting the Camera122
Chapter 8 Target Mini Fixed Rugged Dome123
- Packing List124
Chapter 9 Bullet Camera137
- Packing List140
- Features141
- Overview144
- Installation145
Chapter 10 Ultra Bullet Camera160
- Packing List162
- Features163
- Overview165
- Installation167
  - Waterproofing the Cable171
  - Connecting the Camera173
Chapter 11 Target Bullet Camera176
- Packing List176
- Features177
- Overview178
- Installation180
- Connecting the Camera183
Chapter 12 PTZ Camera185
- Packing List186
- Features187
- Overview188
- Installation190
  - Ceiling Mount190
  - L-Shaped Wall Mount192
- Connecting the Camera195
- Focus Adjustment196
- I/O Terminal Block197
  - Pin Assignment197
  - Voltage Load Expansion (Optional)198
- PTZ Control199
Chapter 13 PT Camera215
- Packing List215
- Features217
- Overview218
- Installation220
- Connecting the Camera220
- Focus Adjustment220
- I/O Terminal Block221
- Pin Assignment221
  - Voltage Load Expansion (Optional)221
- PT Control222
Chapter 14 Vandal Proof IP Dome (Part I)224
- Packing List226
- Features227
- Overview229
- Installation231
  - Hard-Ceiling Mount232
  - In-Ceiling Mount237
- Connecting the Camera240
Chapter 15 Vandal Proof IP Dome (Part II)243
- Packing List245
- Features248
- Overview250
- Installation252
- Connecting the Camera263
Chapter 16 Fixed IP Dome265
- Packing List267
  - Packing List for Hard-Ceiling Mount267
  - Packing List for In-Ceiling Mount268
- Features269
- Overview271
- Installation273
- Connecting the Camera283
- I/O Terminal Block284
  - Pin Assignment284
  - Voltage Load Expansion (Optional)285
Chapter 17 Cube Camera286
- Packing List287
- Features288
- Overview289
- Installation290
- Connecting the Camera292
Chapter 18 Advanced Cube Camera293
- Packing List294
- Features295
- Overview296
- Installation298
- Connecting the Camera300
Chapter 19 Getting Started301
- Accessing the Live View301
  - Checking the Dynamic IP Address303
  - Configuring the IP Address305
- Configuring the Wireless Connection307
- Adjusting Image Clarity311
Chapter 20 Accessing the Camera319
- Accessing Your Surveillance Images320
- Functions Featured on the Main Page321
Chapter 21 Administrator Mode350
- Video and Motion353
- Events and Alerts380
- Monitoring399
  - Monitoring Settings for Target Series400
- Recording Schedule401
  - Recording Schedule Settings401
  - I/O Monitoring Settings402
- Remote Viewlog403
- Network404
- Management418
Chapter 22 Recording and Playback435
- Recording435
- Playback436
Chapter 23 Advanced Applications446
- Upgrading System Firmware446
  - Using the Web Configuration Interface448
  - Using the IP Device Utility449
- Backing up and Restoring Settings452
- Restoring to Factory Default Settings454
- Changing Password468
- Verifying Watermark471
- Downloading Videos from the Micro SD Card474
  - Installing the GV-Sdcardsync Utility475
  - The GV-Sdcardsync Utility Window479
Chapter 24 DVR Configurations481
- Setting up an IP Camera on GV-System488
  - Customizing IP Camera Settings on GV-System491
- Setting up IP Cameras on GV-VMS493
- Remote Monitoring with Multi View496
Chapter 25 CMS Configurations501
- Center V2501
- Vital Sign Monitor504
- Dispatch Server505
Chapter 26 Smart Device Connection507
Appendix508
- Settings for Internet Explorer 8508
- Supported Lenses for Box Camera509
- Resolution and Frame Rate510
- Support Lists516
- RTSP Protocol Command522
- The CGI Command523
- Dual Stream Support List525
- Power Supply Support List528
- Supported Firmware for Flash Memory530
- Supported UMTS Protocol (3G Modem)531
- Specifications: Box Camera (Part 1)532
  - Video Resolution537
  - Power over Ethernet540
  - Web Interface540
- Specifications: Box Camera (Part 2)542
- Specifications: Ultra Box Camera558
- Specifications: Target Box Camera564
  - Video Compression565
  - Video Stream565
  - Network Storage567
  - Live Viewing567
- Specifications: IR Arctic Box Camera568
- Specifications: Mini Fixed Dome (Part 1)583
- Specifications: Mini Fixed Dome (Part 2)589
- Specifications: Mini Fixed Rugged Dome599
- Specifications: Target Mini Fixed Dome608
- Specifications: Target Mini Fixed Rugged Dome613
- Specifications: Bullet Camera (Part 1)618
- Specifications: Bullet Camera (Part 2)628
- Specifications: Ultra Bullet Camera640
- Specifications: Target Bullet Camera652
- Specifications: PTZ Camera657
- Specifications: PT Camera662
- Specifications: Vandal Proof IP Dome (Part 1)668
- Specifications: Vandal Proof IP Dome (Part 2)681
- Specifications: Fixed IP Dome (Part 1)694
- Specifications: Fixed IP Dome (Part 2)700
- Specifications: Cube Camera713
- Specifications: Advanced Cube Camera718
