618

Specifications: Target Bullet

Camera

GV-EBL1100 Series 1/3" progressive scan low lux CMOS


Sensor

GV-EBL2100 Series 1/2.8" progressive scan low lux CMOS

GV-EBL1100 Series 1280 (H) x 1024 (V)


Elements

GV-EBL2100 Series 1920 (H) x 1080 (V)

Color 0.05 Lux

B/W 0.03 Lux

GV-EBL1100

Series

IR ON 0 Lux

Color 0.07 Lux

B/W 0.04 Lux

Minimum

Illumination

GV-EBL2100

Series

IR ON 0 Lux

Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec)

White Balance Automatic, Manual (2800K ~ 8500K)

Gain Control Automatic

GV-EBL1100 Series 50 dB

S/N Ratio

GV-EBL2100 Series 48 dB

WDR Yes

Dynamic Range Up to 72 dB

Lens

Megapixel Yes

Day / Night Yes (with removable IR-cut filter)

Lens Type Fixed Lens
