Germfree BBF 2 - Page 29

DETAILS
XXX-XXXX-XX
- CATEGORY -
BBF-6 USER MANUAL DRAWING
1 OF 1
THIS PRINT IS PROVIDED ON A
RESTRICTED BASIS AND IS NOT TO
BE IS ANY WAY DETRIMENTAL TO
THE INTERESTS OF GERMFREE
LABORATORIES
SIGNATURES
DRAWING NO.
MATERIAL
THICKNESS
DATE
SHEET
REV.
A
P:\Engineering Vault\Employee Folders\Jafa, V\BBF Manual Drawings\BBF-6\E-GERM-003-6000-00.dft
Germfree Laboratories
UNLESS OTHERWISE
SPECIFIED:
TOLERANCES ARE:
.XX =
±
.03
.XXX =
±
.010
FRACTIONS =
±
1
16
ANGLES =
±
.5
°
DIMENSIONS ARE IN
INCHES.
DO NOT SCALE DRAWING.
SHEET NAME
DRAWN BY:
APPROVAL:
XX/XX/XX
05/08/20
B.SERLE
T. JAFA
CHECKER:
B.SERLE
XX/XX/XX
N/A
MATERIAL
FINISH
N/A
N/A
REVISIONS
Rev Description Date Drawn By Checked By Approved
A INITIAL RELEASE xx/xx/xx XXX XXX XXX
FRONT VIEW
TOP VIEW
A
A
SIDE VIEW
(SECTION A-A)
72 1/8
57
29 3/8
16 3/8
27
14 1/2
16 1/2
6 1/8
