Installation and Operation
Manual
Series A3 & A4
The Sensocon A3 and A4 series of differential pressure controllers provide control
of low differential pressure applications for air and other compatible non
combustible gasses. These instruments have a large LED display for pressure
indication, a LCD or OLED display for programming and additional LED’s to
indicate % of output, setpoints and alarm status. The instruments are fully
programmable from the key pad face or by utilizing the Opti-Link™
communication port for no touch programming. Options for the instruments
include a 4-20 mA output, and improved accuracies. There is also a low cost
weatherproof cover available for outdoor applications.
Example
A3110-06
Description
Model
A
Round Panel Mount Housing
3
LED display, process arch, LCD
Display
4
LED display, process arch, OLED
Control
1
Control 2 SPDT relays
0
None
Transmitter
1
4-20 mA
0
1%
Accuracy
1
0.50%
-
01
0 – 0.50”
-
02
0 – 1”
-
03
0 – 2”
-
04
0 – 3”
-
05
0 – 4”
-
06
0 – 5”
-
07
0 – 8”
-
08
0 – 10”
-
09
0 – 15”
-
10
0 – 20”
Range
-
11
0 – 30”
Maximum Pressure: Ranges ≤ 4” w.c. = 2 PSI; Ranges ≥ 5” w.c. = 10 PSI
Media compatibility: Air and compatible non combustible, non corrosive gasses
Accuracy*: Axxx0-xx - 1.00%; Axxx1-xx - 0.50%
Temperature Ranges:
Compensated: -10° to 140°F (-23° to 60°C)
Operating: -10° to 140°F (-23° to 60°C); A3: 10° to 140°F (-12° to 60°C)
Thermal Effect*: +/- 0.012% FS/°F
Output Signal: 4-20 mA (option)
1. INTRODUCTION
1.1 Model Number Configuration
1.2 Specifications
