Surface Mounting – Surface mounting the Series A3 or A4 requires the optional
weather proof cover. Once the control is wired and the weather proof cover has
been attached, the control can be mounted to any flat surface with the four
mounting screws provided with the cover.
Flush Mounting with Weather Proof cover – The Series A3 and A4 can also be
flush mounted with a weather proof cover. The procedure is the same as above,
but utilizes two extra long mounting screws (provided with the weather proof
cover) for the bottom two panel connections.
