75
Parts
PartsParts
Parts Specifications
SpecificationsSpecifications
Specifications
Optional One of the below options on the top side:
RS232 / RJ-45 / microSD / barcode reader
LAN (option) 10/100/1000 Mbps Ethernet
Wireless LAN + BT Intel® 7265 2x2 802.11 AC + BT 4.0 combo
GPS (option) UART
WWAN (option) 3G/4G LTE
Camera (option) Front: FHD
Rear: 8M pixel, autofocus, LED, video capture
Power AC adapter Universal 65 W; input: 100∼240 V
, 50/60 Hz; output:
19V
Battery pack Lithium-ion Prismatic type, 4-cell
Dimension (LxW×D) 227 x 150 x 23.7 mm (8.93 × 5.90 × 0.93 inch)
Weight 950 g (2.09 lb)
Button
Button Button
Button Functions
Functions Functions
Functions on Special Occasions
on Special Occasionson Special Occasions
on Special Occasions
On “POST/BIOS Setup/Non-ACPI” occasions, the five hardware buttons provide
keyboard key functions as described below.
Button
ButtonButton
Button Function
FunctionFunction
Function
Tab
Esc
Enter
↑
↑↑
↑ Up
