ERROR CODES IN THE MACHINE
Error codes indicate that a serious error has occurred in the machine or the washing process. The er-
URUPXVWEHSXWULJKWE\DQDXWKRUL]HGVHUYLFHWHFKQLFLDQ
7KHIROORZLQJHUURUFRGHVPD\RFFXU
Error code Description of error
A00 POWER FAIL Power failure
A01 OVER FLOW CH Overfilling of the machine. The alarm goes on immediately after the level sensor
is activated.
A02 SLOW FILL Wash chamber slow to fill. The level sensor at the inlet loses the signal for more
than 20 sec.
A03 OVER FLOW CO Overfilling in condenser Level sensor is activated for more than 5 sec.
A04 SLOW DRAIN Chamber slow to empty. Level sensor in the chamber is not activated after 2 tries
at emptying.
A05 LEAK DRYER Water leakage in the dryer.
A06 UNLOCK DOOR The door is not unlocked within 4 seconds from the time the unlocking button is
pressed.
A14 SLOW DOS 1 Low flow of detergent 1.
No flow (2 ml) within 5 sec of dosing.
A15 SLOW DOS 2 Low flow of detergent 2.
No flow (2 ml) within 5 sec of dosing.
A16 SLOW DOS 3 Low flow of detergent 3.
No flow (2 ml) within 5 sec of dosing.
A17 SLOW DOS 4 Low flow of detergent 4.
No flow (2 ml) within 5 sec of dosing.
A21 CIRC PRESS L Pressure from circulation pump has not reached 30 kPa after 20 sec after
completing water filling. Check that the water reaches the machine.
A23 DRYER TEMP L Low temperature in dryer. The temperature in the dryer has not increased to 70°C
within one minute of the dryer starting.
A25 T SENS CHAMB Faulty temperature sensor in the chamber.
A26 I SENS CHAMB Faulty independent of temperature sensor in the chamber.
A28 SLOW HEAT CH Low temperature in the chamber The temperature has not increased by 5°C within
5 min
A29 T DIFF CHAMB Difference between sensors in the chamber are more than 3°C
A30 CHAMB TEMP H The temperature in the chamber is more than 5°C above the highest reference point.
A33 DISINF TEM L Final rinse time + 60 sec.
<Doc_USR><Doc_503901100><Rel_A><Lang_EN>
Page 20 of 28
