PT100 Thermocouple failure
A fault (warning) is logged if the lamp cable is not connected, if the PT100 fails or if the
temperature reaches its top range.
• Check electrical connections between the
e
-Brick and the lamp head
• Check the lamp chassis is fully inserted in the lamp head; ensure that the plug to the
lamp head is fully engaged
• Replace PT100 if failure is suspected
Note! The system will still run with this warning present
•
Communication Failure
If a communication failure is detected with an
e
-Brick slave more information is now
available on the HMI. When a selected
e
-Brick fails to communicate, a pop-up message
appears “COMMUNICATION FAILURE. SEE FAULT SCREEN & DESELECT LAMP
ACCORDINGLY”.
• Check ‘Fault’ screen to identify which
e
-Brick has failed to communicate
• Check electrical connections to the affected slave
• Check 24V LED is illuminated, if not then internal 24Vdc may be faulty
• Check K1 LED illuminates when lamp is selected
• If no fault found, try restarting system and reselecting lamps
• If necessary, deselecting affected slave
e
-Brick will allow system to run
Other
warnings.
Some applications may have additional fault codes; refer to the specific software
users manual for explanations of other fault codes.
GEW UV
e
-Brick installation and operating manual 40 of 49
