2. Transport, Handling, Storage
2.1. Storage
The standard packaging comprises a sealed polythene bag with silica gel pack to protect against
condensation due to temperature variation; the
e -Brick is fitted with preformed protective end
caps and placed in a tri-wall cardboard container which provides transit and storage protection. A
number of
e -Brick packages may be palletised for ease of handling during shipment.
22kW products are packed in a sealed polythene bag with silica gel pack then secured to a pallet
with a shock protection layer.
During transportation and prior to installation the
e -Brick shall be stored in its protective
packaging.
The recommended storage temperature range is –25°C to +55°C with up to 24h at 70°C.
2.2. Dimensions
See following tables for dimensions of the e -Brick product variants, and standard packaging:
Standard packaging
e -Brick variant Length (mm) Width (mm) Height (mm) Weight (kg)
9kW 760 440 440 26
12kW 1010 440 440 37
e -Brick product
e -Brick variant Length (mm) Width (mm) Height (mm) Weight (kg)
9kW 625 280 275 22.5
12kW 875 280 275 33
22kW 875 560 275 85
