GEZE ECturn User Manual

ECturn & ECturn Inside
11
Description
Switch/push button/action What does the switch/push button do?
Key switch of the display programme switch If a key switch is connected to the display programme
switch, the operation of the display programme switch
can be locked or released with it.
Activation device with radio board Door opens once and closes after the hold-open time. The
set mode of operation is retained.
If the key in radio channel 1 is pressed for longer than 5s,
the control unit changes to the DO mode of operation.
After the key has been pressed again for at least 5s, the
control unit changes back to the AU mode of operation.
Switch function The automated door can be activated using the switch
function.
Normal switch function:
à Switch contact opens the door and the door remains in
the open position.
à Switch contact closes the door.
Switch function with hold-open time:
à Switch contact opens the door.
à Switch contact closes the door or the door starts to
close after the hold-open time.
WC control The door opens after the elbow switch on the outside of
the toilet has been pressed, and closes automatically after
the set hold-open time has passed.
When the push button is activated inside the toilet cabin,
the system is switched to the Night mode of operation,
which means the outer push button no longer opens the
door. At the same time, the lights indicate that the toilet is
occupied.
The electric strike is supplied with current, preventing
manual opening of the door from outside.
Activating the "inner" push button again or through man-
ual opening from inside, the WC function (Night mode of
operation) is cancelled and the drive switched back to the
automatic mode of operation.
The ‘occupied’ displays and lights go out.
Push & Go When the door is pressed manually out of the closing
system with an activated Push & Go function in the Auto-
matic mode of operation, the door opens automatically as
soon as a specic adjustable opening angle is exceeded.
Push To Close If the door is closed manually a few degrees while the
hold-open time runs down
and the Push To Close function is activated,
then it closes to the closing position
automatically. Depending on the set parameter, manually
closing by a few degrees from the
hold open position switches the mode of operation to
automatic
and the door closes automatically.
Contact sensor K /
Hold open
Door opens once and closes after the hold-open time.
AU mode of operation is retained. If the push button is
pressed for longer than 5 s, the control unit changes to the
DO mode of operation. After the push button has been
pressed again, the control unit changes back to the AU
mode of operation.
210623_GEZE_ID 196257-00_BHB-ECturn_EN.indd 11 7/18/2021 14:00:31
