GFI System SYNESTHESIA User Manual

UserManual
SYNESTHESIA

(FirmwareV1.0.2)
9
Chapter2‐EXTERNALCONTROL
Synesthesiaprovidesahighlyversatile systemforexternalcontrol.TheACEinputjackaccepts3typesofexternalcon‐
trol:
 1,2,or3buttonsAuxswitches.
 ControlVoltage.
 Expressionpedal.
Uponpowerup,Synesthesiawillsensethepresence(orabsence)ofanyofthe3possibleinput
sourcesandconfigure
theinternal processing accordingly. Onceasource type is detectedthe pedal willhold that information until thenext
powerup,thus ifyouarechangingthe source(say,froman aux switchto anexpressionpedal) youmust powercycle
thepedal,andletitsenseandrecognizethenewsource.
2.1AUXSWITCHES
External switches are absolutely wonderful for unlocking the rich potential of user’s control and access to the various
featuresandfunctionalities.Here’sthelistoffunctionsthatyoucanassigntotheswitches:
3‐Buttonswitchbox
2‐Buttonswitchbox
1‐Buttonswitchbox
TRScable&plug
TRScable&plug
TScable&plug
Normally‐Opened,
Momentary
SwitchfunctionassignmentcanbesetinGlobals(Globals‐>AuxTIP
Globals‐>AuxRING
Globals‐>AuxTIP+RING).
 BankUp
 BankDown
 PageUp
 LoadPatch‐A
 LoadPatch‐B
 FavoritePreset
 Bypass/Engage
 ToggleModes
 TapTempo
 InstantRamp‐Y DSP‐XOn/Off
 DSP‐YOn/Off
 InstantRamp‐X
T R S
T S
2.2CONTROLVOLTAGE(CV)
TScable&plug
CVgeneratingdevices
+2.5V
0V
Connectacontrolvoltagesource(synthesizers,sequencers,etc)fordirectcontrolofthealgorithm’sparameters.
T S
acceptablerange
