Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 13 of 60
4.3 Explanations to the diesel en-
gine drive tubing plan
The pressures stated are abso-
lute pressures.
4.3.1 Start-up
Suction valve [4] is on idle position (minimum
discharge) as no control pressure is applied
yet.
To allow for intake of a small amount of air for
pressure built-up, the throttle valve [5] is set
as to provide for a pressure of > 0.1 bar
ahead of the compressor. An incorrect con-
struction/design of suction valve might cause
problems/damages with/of compressor.
Throttle valve [5] is required only
if suction valve [4] does not have
an adjusting possibility for di-
rected leakage (e.g. provision of
bores in a throttle).
Hand switch [23] is closed.
Load position: Electric circuit for relief valve
[16] and the 3/2 way valve [20] is closed.
At the start of the motor, relief valve [16] (idle:
open), the 3/2 way valve [20]. The diesel en-
gine is running with minimum speed.
Minimum pressure valve [17] is closed, thus
separating the compressor system from the
mains. Minimum pressure valve must be ad-
justed to a minimum pressure of 4.5 bar.
To protect motor and coupling [2], starting the
motor should only be possible if there is a
maximum pressure of 2 bar behind the com-
pressor.
4.3.2 Operation under load
When required control pressure has been
reached, control cylinder [40] regulates the
diesel engine to maximum speed and suction
valve [4] opens at the same time.
Minimum pressure valve [17] opens only after
a pressure of approx. 4.5 bar has built-up in
the compressor system. This pressure en-
sures a sufficient oil supply of the compressor
during operation under load.
The compressor boosts into the mains as
soon as the system pressure ahead of non-
return valve [18] exceeds the pressure of the
mains.
4.3.3 No-load operation
No-load operation is possible:
1. Automatically in case of mains pressure is
higher than the upper switch-point of pres-
sure controller [19].
2. Upon actuation of hand switch [23]. (No-load
position: Power supply for relief valve [16]
and 3/2 way valve [20] is interrupted).
The sequence is identical:
3/2 way valve [20] closes because of the ab-
sence of current. The absence of control
pressure regulates the diesel engine to mini-
mum speed and opens suction valve [4] at
the same time.
At the same time, the absence of current o-
pens relief valve [16], the pressure in the
compressor system drops.
Non-return valve [18] separates the com-
pressor system from the mains.
(In addition, minimum pressure valve [17]
closes at a pressure of approx. 4.5 bar).
As the mains pressure drops and reaches the
lower switch-point, pressure controller [19]
again closes the electric circuit.
This makes relief valve [16] close and 3/2 ]
way valve [20] open.
The control pressure from the mains immedi-
ately regulates the diesel engine to maximum
speed and opens suction valve [4] at the
same time by means of non-return valve [22]
and control cylinder [40]. Further sequence
as described under “Operation under load“.
NOTE
NOTE
