Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 24 of 60
7 Spare parts
A long-lasting reliable operation of the compressor unit is ensured by regular renewal of wear- and tear
parts. Please see the spare parts kits chart below (Standard-Kits are shaded).
Konditionsblatt Ersatzteil-Kits
Öleingespritzte Standardkompressoren
Spare Part Kits for oilinjected standard airends
Typ Zeichnungs-Nr. * Kompressor-Kit SB Kompressor-Kit Light SB Getriebe-Kit SB Abdichtungs-Kit SB
Type Drawing number Compressor Kit Compressor Kit Light Gear Kit Sealing Kit
CF75D/D3
401-0-003929
83903537
2
83903538
5
CF75D5/D6/D8
22415269
83903706
5
C22696058
0
83901863
10
CF75D7
401-1-005707
83903389
0
83903390
0
CF75G1
400-0-028934
83903539
0
CF75G2
401-0-002625
83903540
0
CF75G
22950968
83901385
10
C22696066
0
83901384
0
83901383
10
CF90D/LD
400-0-044569
83903541
2
83903542
5
CF90D2/D3/LD1
22549836
83903543
10
C22696074
0
83903544
10
CF90G/G2/LG/LG2
400-0-015202
83901543
5
C22696090
0
83901542
2
83900808
5
CF90G5/G8/LG3/LG5
22552616
83901550
5
C22696330
0
83901549
0
83901548
3
CF90G6
401-0-005253
83901589
0
CF128D/D2/LD
400-1-017757
83900827
3
C22696108
0
83900815
3
CF128G/G2/LG/LG2
400-1-016770
83900972
5
C22696116
0
83900826
5
83900825
5
CF128R/LR
22483382
C22875272
2
C22875736
0
C22875298
0
CF180D
400-0-039919
83903545
1
83903546
0
CF180R/RB
401-0-003329
83903548
3
83903549
3
CF180G
400-0-039920
83900812
2
83900979
1
83900978
2
CF180G1
400-0-039920
83900979
1
83900978
2
CF180G2
401-0-003580
83903547
C22696124
0
83900979
0
83900978
0
CF246G
400-0-045266
83903873
1
C22784540
0
83903874
1
83903875
0
* please note current revision status
