Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 29 of 60
CF75D6/D8 Technical data (Page 1 of 2)
Dimensions: 416 mm x 251 mm x 210 mm (LxWxH)
Weight: 58 kg
Permissible areas of operation:
min max
Speed of male rotor 1450 1/min 8935 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 16 bar(abs)
Discharge temperature 110°C
Belt drive permitted YES
* without additional oil pump
