Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 37 of 60
CF90D3/D4 Technical data (Page 1 of 2)
Dimensions: 480 mm x 315 mm x 255 mm (LxWxH)
Weight: 88 kg
Permissible areas of operation:
min max
Speed of male rotor 1450 1/min 7446 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 16 bar(abs)
Discharge temperature 110°C
Belt drive permitted YES
* without additional oil pump
