Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 42 of 60
CF90LG5 Technical data (Page 1 of 3)
Dimensions: 803 mm x 373 mm x approx 320 mm (LxWxH)
Weight: 132 kg
Permissible areas of operation:
min max
Speed of male rotor 1489 1/min 7446 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 11,5 bar(abs)
Discharge temperature 110°C
Gear ratio 2,3548 3,0000
* without additional oil pump
