Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 48 of 60
CF128R Technical data (Page 1 of 2)
Dimensions: 722 mm x 433 mm x 370 mm (LxWxH)
Weight: 265 kg
Permissible areas of operation:
min max
Speed of male rotor 1047 1/min 5235 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 16 bar(abs)
Discharge temperature 110°C
Belt drive permitted YES
* without additional oil pump
