Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 58 of 60
CF246G Technische Daten (Blatt 1 von 3)
Dimensions: 1519 mm x 791 mm x 830 mm (LxWxH)
Weight: 1600 kg
Permissible areas of operation:
min max
Speed of male rotor 575 1/min 2875 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 14,5 bar(abs)
Discharge temperature 110°C
Gear ratio 0,4605 1,9211
* without additional oil pump
