Giant TRINITY ADVANCED PRO - Di2 Derailleur Cable Routing

Version 9 /2015
18
DERAILLEUR/BRAKE CABLE HOUSING
GUIDELINE & CABLE ROUTING
To ensure optimal shifting and braking operation, proper cable housing
length is essential. Please see the following guideline for cable housing
length for each system and frame size
Di2 derailleur parts list & cable routing
-Cable Length (mm)
Size
A
B
C
D
E
XS
350
1000
950
250
750
S
350
1000
950
250
750
M
350
1000
950
250
750
L
350
1000
950
250
750
A
Detail A
Detail B
B
C
D
E
D
