Giant TRINITY ADVANCED PRO - AeroVault Toptube Box Assembly (Di2)

Version 9 /2015
21
AeroVault Toptube Box Assembly (Di2)
The toptube box is secured with M5 screws.
Slide the Di2 control box into the allocated position in the bento box after
plugging in the Di2 wires.
By pressing down on the blue location, the cover is secured in the closed
position. Storage space is accessible from this position via the sides of the
toptube box soft cover.
M5
M5
