Giant TRINITY ADVANCED PRO - Di2 Battery Seatpost Installation

Version 9 /2015
23
Di2 Battery Seatpost Installation
-Assembly
Assemble the dilator and support base
affixed to the outer wall of the battery
After assembling, insert into seat tube
then lock dilator with M4 screws to fix
battery inside the seatpost.
-Charging
Open the toptube box cover, remove the
Di2 junction box EW90
Open the anti-dust cover, plug in the
charging cable to charge the battery
