Gibertini EU-C LCD - EURO Protocol; PRINTER Potocol

ENGLISH
EU-C “LCD”
- 34 -
Status codes of F2 character
S
Measure is stable (stable)
I
Measure is not stable (unstable)
E
Error
A
Zero aquisition
L
Load weight (only for manual calibration LOAD)
U
Unload weight (only for manual calibration UNLOAD)
D
Calibration done
B
Calibration busy
P
Percentage
7.2.2 EURO Protocol
In this protocol the answer to any type of command is formatted with a measure field:
D0
D1
D2
D3
D4
D5
D6
D7
CR
LF
1
2
3
4
5
6
7
8
9
10
The measure field (1…8) is the weight on the pan.
It is right justified with decimal point and measure sign (a space character for positive
measure or a “-“ character for a negative measure).
Field 9 and 10 are:
CR ASCII code for carriage returns
LF ASCII code for line feed
7.2.3 PRINTER Potocol
It is selected by the option “PRINTER” in the SETUP menu.
The output string is the same of the “CRYSTAL” protocol but the status flags are not
transmitted. The transmission is activated by the PRINT pushbutton if and only if the
protocol selected is “PRINTER” and the data is stable.
The output string uses 10 characters for the measure including sign, decimal point and the
value, right justified.
The string format is:
a measure field
a unit field
The format of the output is:
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
B
U
U
U
CR
LF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
The measure field (1…10) is the weight on the pan. It is right justified with decimal point
and measure sign (a space character for positive measure or a “-“ character for a negative
measure).
Unit field (12, 13, 14) shows the current unit of measurement.
B field (11) is the blank character.
Field 15 and 16 are:
CR ASCII code for carriage returns.
LF ASCII code for line feed.
