EU-C “LCD”
ENGLISH
- 29 -
▪ By pressing for less than one second the MODE key, all the available options are
visualised (oz, lb, ct, Pcs, %). Once that the desired unit is selected, press the ON-
OFF key to confirm
▪ The balance returns to operating mode and begins automatically to weigh with the
newly selected unit.
When a second unit of measurement is selected, it is automatically stored in the balance
memory, and the setting will be maintained also when the power supply cable is
disconnected.
Moreover, once that the alternative unit is stored, it is possible to shift instantaneously
between the default unit (grams) and the second unit selected by pressing the MODE key
for less than one second.
This choice allows comparing instantaneously the same weight in two different units of
measurement. This function works with all the second units of measurement in the
balance.
6.2 “SETUP” MENU
It is the second menu visualised once entered in configuration mode. Through its sub-
menu it is possible to modify and store the main parameters of the balance; always using
the MODE key to scroll, the ON-OFF key to confirm and the ZERO-T key to exit from
selection mode. The sub-menu and their options are:
SERIAL
BAUD
➔
Defines the transmission baud rate of the serial output
from 1200 to 38400 baud (default 9600).
BYTE FOR
➔
Defines the format of the byte transmitted that may be
selected between the following (default 7E1):
Data format
Data bit
Parity type
Bit stop
7 E 1
7
EVEN
1
7 0 1
7
ODD
1
7 N 2
7
NO PARITY
2
7 E 2
7
EVEN
2
7 O 2
7
ODD
2
8 N 1
8
NO PARITY
1
8 E 1
8
EVEN
1
8 O 1
8
ODD
1
8 N 2
8
NO PARITY
2
PROTOC
➔
EUROPE
➔
With this protocol the answer to any
type of command is formatted with a
measure field.
➔
CRYSTAL
➔
(Default) With this protocol the answer
to any type of command is formatted
with: a data field, a unit field and a
status field
➔
PRINTER
➔
Protocol used to drive external printers.
N.B.- For more informations referring to Section 7 - SERIAL
TRANSMISSION.
