GIGA-BYTE TECHNOLOGY X570S AORUS MASTER User Manual

- 11 -
Hardware Installation
(Note1) ForAMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series Processors only.
(Note2) ForAMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
4000G-SeriesProcessors/AMDRyzen
™
3000SeriesProcessors/AMDRyzen
™
2000 Series Processors only.
Expansion Slots  1 x PCI Express x16 slot (PCIEX8), integrated in the CPU:
- AMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series Processors
support PCIe 4.0 x8 mode
- AMDRyzen
™
4000G-SeriesProcessors/AMDRyzen
™
2000 Series Processors
support PCIe 3.0 x8 mode
- AMDRyzen
™
3000G-SeriesProcessors/AMDRyzen
™
2000 G-Series Processors
do not support this slot
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot operates at up to x8 mode.
 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
- Supporting PCIe 4.0
(Note 1)
/3.0x4mode
* The PCIEX4 slot shares bandwidth with the M2C_SB connector. The PCIEX4 slot
becomes unavailable when a device is installed in the M2C_SB connector.
Multi-Graphics
Technology
(Note 2)
 Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,
Mkey,type2242/2280/22110SSDs:
- AMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series
ProcessorssupportSATAandPCIe4.0x4/x2SSDs
- AMDRyzen
™
4000G-SeriesProcessors/AMDRyzen
™
3000 G-Series
Processors/AMDRyzen
™
2000SeriesProcessors/AMDRyzen
™
2000 G-Series
ProcessorssupportSATAandPCIe3.0x4/x2SSDs
 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3,
Mkey,type2242/2280/22110SSDs:
- Supporting PCIe 4.0
(Note 1)
/3.0x4/x2SSDs
 2xM.2connectors(M2C_SB/M2D_SB),integratedintheChipset,supporting
Socket3,Mkey,type2242/2280/22110SSDs:
- Supporting SATA and PCIe 4.0
(Note 1)
/3.0x4/x2SSDs
 6xSATA6Gb/sconnectors,integratedintheChipset:
- Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB  CPU:
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports on the back panel
 Chipset+ASMedia
®
USB 3.2 Gen 2x2 Controller:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
 Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 4 x USB 3.2 Gen 1 ports, available through the internal USB headers
