Hardware Installation
USB  Chipset+2 USB 2.0 Hubs:
 - 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connectors
 1 x CPU fan header
 1 x water cooling CPU fan header
 4 x system fan headers
 4xsystemfan/watercoolingpumpheaders
 2 x addressable LED strip headers
 2 x RGB LED strip headers
 1xCPUcoolerLEDstrip/RGBLEDstripheader
 4 x M.2 Socket 3 connectors
 6xSATA6Gb/sconnectors
 1 x front panel header
 1 x front panel audio header
 1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
 2 x USB 3.2 Gen 1 headers
 2xUSB2.0/1.1headers
 1 x noise detection header
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x Thunderbolt
™
add-in card connector
 2 x temperature sensor headers
 1 x power button
 1 x reset button
 1 x Clear CMOS jumper
 Voltage Measurement Points
Back Panel
Connectors
 1 x Q-Flash Plus button
 1 x Clear CMOS button
 2 x SMA antenna connectors (2T2R)
 1 x USB Type-C
®
port, with USB 3.2 Gen 2x2 support
 5 x USB 3.2 Gen 2 Type-A ports (red)
 2 x USB 3.2 Gen 1 ports
 4xUSB2.0/1.1ports
 1 x RJ-45 port
 1xopticalS/PDIFOutconnector
 5 x audio jacks
I/OController

iTE
®
I/OControllerChip
