Gigabyte GA-X58A-OC User Manual

- 41 - BIOS Setup
>>>>> Advanced Clock Control
CPU Clock Drive
Allows you to adjust the amplitude of the CPU and Chipset clock.
Options are: 700mV, 800mV (default), 900mV, 1000mV.
PCI Express Clock Drive
Allows you to adjust the amplitude of the PCI Express and Chipset clock.
Options are: 700mV, 800mV, 900mV (default), 1000mV.
CPU Clock Skew
Allows you to set the CPU clock prior to the Chipset clock.
Options are: 0ps~750ps. (Default: 0ps)
IOH Clock Skew
Allows you to set the North Bridge clock prior to the CPU clock.
Options are: 0ps~750ps. (Default: 0ps)

Advanced Memory Settings
Extreme Memory Prole (X.M.P.)
(Note)
, System Memory Multiplier (SPD),
Memory Frequency(Mhz)
The settings under the three items above are synchronous to those under the same items on the Ad-
vanced Frequency Settings menu.
Performance Enhance
Allows the system to operate at three different performance levels.
Standard Lets the system operate at its basic performance level.
Turbo Lets the system operate at its good performance level. (Default)
Extreme Lets the system operate at its best performance level.
DRAM Timing Selectable (SPD)
Quick and Expert allows the Channel Interleaving and Rank Interleavingitems tobecongurable.
Options are: Auto (default), Quick, Expert.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Memory Settings
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

 ExtremeMemoryProle(X.M.P.)
(Note)
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
Performance Enhance [Turbo]
DRAM Timing Selectable (SPD) [Auto]
 ProleDDRVoltage   1.5V
 ProleQPIVoltage   1.15V 
x Channel Interleaving 6 Auto
x Rank Interleaving 4 Auto
>>>>> Channel A

Channel A Timing Settings [Press Enter]

Channel A Turnaround Settings [Press Enter]
>>>>> Channel B

Channel B Timing Settings [Press Enter]

Channel B Turnaround Settings [Press Enter]
>>>>> Channel C

Channel C Timing Settings [Press Enter]

Channel C Turnaround Settings [Press Enter]
(Note) This item is present only when you install a memory module that supports this feature.
