Gigabyte MZ72-HB2 User Manual

- 10 -
Hardware Installation
Socket
Socket
Security
Security
Internal I/O
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connectors
 5 x SlimSAS connectors
 4 x SATA 7-pin connects
 1 x M.2 slot
 2 x CPU fan headers
 4 x System fan headers
 1 x USB 3.0 header
 1 x USB 2.0 header
 1 x TPM header
 1 x Front panel header
 1 x PMBus connector
 1 x IPMB connector
 1xClearCMOSjumper
 1xBIOSrecoveryjumper
Socket
Socket
Security
Security
Rear I/O
Connectors
 2 x USB 3.0 ports
 1 x VGA port
 1 x Serial port
 2 x RJ45 ports
 1 x MLAN port
 1 x ID button with LED
Socket
Socket
Security
Security
TPM  1 x TPM header with SPI interface
 Optional TPM2.0 kit: CTM010
Socket
Socket
Security
Security
Board
Management
 Aspeed® AST2600 management controller
 GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
 Dashboard
 HTML5 KVM
 Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
 Sensor Reading History Data
 FRU Information
 SEL Log in Linear Storage / Circular Storage Policy
 Hardware Inventory
 FanProle
 System Firewall
 Power Consumption
 Power Control
 LDAP / AD / RADIUS Support
 Backup&RestoreConguration
 Remote BIOS/BMC/CPLD Update
 Event Log Filter
 User Management
 Media Redirection Settings
 PAM Order Settings
 SSL Settings
 SMTP Settings
