Gigabyte MZ72-HB2 User Manual

- 9 -
Hardware Installation
1-2 Product Specications
Socket
Socket
Security
Security
Form Factor
 E-ATX
 305W x 330D (mm)
Socket
Socket
Security
Security
CPU  AMD EPYC™ 7003 series processor family
 Dual processors, 7nm, Socket SP3
 Up to 64-core, 128 threads per processor
 cTDP up to 280W
 Compatible with AMD EPYC™ 7002 series processor family
Socket
Socket
Security
Security
Chipset  System on Chip
Socket
Socket
Security
Security
Memory  16 x DIMM slots
 DDR4 memory supported only
 8-Channel memory architecture
 RDIMM modules up to 128GB supported
 LRDIMM modules up to 128GB supported
 3DS RDIMM/LRDIMM modules up to 256GB supported
 Memory speed: Up to 3200/ 2933 MHz
Socket
Socket
Security
Security
LAN  2 x 10GbE LAN ports (1 x Broadcom® BCM57416)
 1 x 10/100/1000 management LAN
Socket
Socket
Security
Security
Onboard
Graphics
 Integrated in Aspeed® AST2600
 2D Video Graphic Adapter with PCIe bus interface
 1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Security
Security
Storage Interface  4 x 7-pin SATA 6Gb/s ports
 *3 x SlimSAS (with 12 x SATA 6Gb/s or 3 x NVMe PCIe Gen4 x4) ports
 1 x M.2 slot:
- M-key
- PCIe Gen4 x4
- Supports NGFF-2280/22110 cards
 2 x NVMe ports:
- SlimSAS 4i type
- PCIe Gen4 x4 per port
*Note!
Default setting is SATA, please go to BIOS Setup section, Advances>PCI Sub-
system setting for advanced conguration manually.
Socket
Socket
Security
Security
Expansion Slots  Slot_6: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_0)
 Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_0)
 Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot ( from CPU_1)
 Slot_2: 1 x PCIe x16 (Gen4 x8 bus) slot ( from CPU_0)
 Slot_1: 1 x PCIe x16 (Gen4 x8 bus) slot ( from CPU_1)
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.
