- 18 -
Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
•
First make sure your devices are compliant with the connectors you wish to connect.
•
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
•
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX 11) F_USB2
2) P12V_1 (for CPU0) 12) FP_1
3) P12V_2 (for CPU1) 13) BP_1
4) SATA0/SATA1/SATA2/SATA3 14) SPI_TPM
5) SATA_SGP 15) IPMB
6) CPU0_FAN/ CPU1_FAN 16) CN_NSCI
7) SYS_FAN1/SYS_FAN2 17) LED_BMC
8) SYS_FAN3/SYS_FAN4 18) BAT
9) PMBUS 19) CASE_OPEN
10) F_USB3 -- --
CPU0
CPU1
DIMM_P0_A0
DIMM_P0_B0
DIMM_P0_C0
DIMM_P0_D0
DIMM_P0_H0
DIMM_P0_G0
DIMM_P0_F0
DIMM_P0_E0
DIMM_P1_L0
DIMM_P1_K0
DIMM_P1_J0
DIMM_P1_I0
DIMM_P1_M0
DIMM_P1_N0
DIMM_P1_O0
DIMM_P1_P0
7
15
17
18
16
1
2
3
8
9
10
11
12
13
14
19
