User Guide

GD32E507Z-EVAL

27/43

5.17. CAN

5.17.1. DEMO purpose

This demo includes the following functions of GD32 MCU:

 Learn to use CAN0 to realize communication between two boards.

 Learn to use USART module to communicate with the HyperTerminal.

5.17.2. DEMO running result

This demo is tested with at least two GD32E507Z EVAL board. Jump the P2, P3 to CAN

with the jumper cap. Conne ct L pin to L pin and H pin to H pin of JP11 on the boards for

sending and receiving frames. Use a jumper cap to jump JP13 to USART0. Download

the program <17_CAN_Network> to the EVAL boards, and connect serial cable to

USART0. When user press the KEY_B, the frames are sent and the data are printed.

When the frames are received, the data of receiving will be printed and the LED2 will

toggle once. The output information via the serial port is as following.
