User Guide

GD32E507Z-EVAL

6/43

1. Summary

GD32E507Z-EVAL uses GD32E507ZET6 as the main controller. It uses GD-Link Mini USB

interface to supply 5V power. Reset, Boot, K2, LED, I2S, I2C-EEPROM, LCD, NAND Flash,

SQPI-Flash, USB, Ethernet and USART to USB interface are also included. For more details

please refer to GD32E507Z-EVAL-Rev1.1 schematic.

2. Function Pin Assign

Table 2-1. Function pin assignment

Function

Description

LED

PG10

LED1

PG11

LED2

PG12

LED3

PG13

LED4

RESET

K1-Reset

KEY

PA0

KEY_A

PC13

KEY_B

PF13

KEY_C

PF14

KEY_D

PF15

KEY_Cet

ADC

PC2

ADC01_IN12

PC3

ADC01_IN13

DAC

PA4

DAC_OUT0

CAN

PD0

CAN0_RX

PD1

CAN0_TX

USART

PA9

RS232_TX

PA10

RS232_RX

I2C

PB6

I2C0_SCL

PB7

I2C0_SDA

I2S

PB15

I2S1_SD

PB13

I2S1_CK

PB12

I2S1_WS

PC6

I2S1_MCK

SQPI

PF8

SQPI_CLK

PF6

SQPI_CSN

PF0

SQPI_D0

PF4

SQPI_D1

PF2

SQPI_D2

PF10

SQPI_D3

NAND Flash

PD14

EXMC_D0
