Function
Pin
Description
PD15
EXMC_D1
PD0
EXMC_D2
PD1
EXMC_D3
PE7
EXMC_D4
PE8
EXMC_D5
PE9
EXMC_D6
PE10
EXMC_D7
PD11
EXMC_A16
PD12
EXMC_A17
PD4
EXMC_NOE
PD5
EXMC_NWE
PD6
EXMC_NWAIT
PD7
EXMC_NCE1
LCD
PD14
EXMC_D0
PD15
EXMC_D1
PD0
EXMC_D2
PD1
EXMC_D3
PE7
EXMC_D4
PE8
EXMC_D5
PE9
EXMC_D6
PE10
EXMC_D7
PE11
EXMC_D8
PE12
EXMC_D9
PE13
EXMC_D10
PE14
EXMC_D11
PE15
EXMC_D12
PD8
EXMC_D13
PD9
EXMC_D14
PD10
EXMC_D15
PE2
EXMC_A23
PD4
EXMC_NOE
PD5
EXMC_NWE
PG9
EXMC_NE1
Ethernet
PB11
RMII_TX_EN
PB12
RMII_TXD0
PB13
RMII_TXD1
PC4
RMII_RXD0
PC5
RMII_RXD1
PA7
RMII_CRS_DV
PC1
RMII_MDC
PA2
RMII_MDIO
