11
www.gigaipc.com
Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)
Table Contents
mITX-Q47EA Mini-ITX Motherboard 1
User’s Manual 1st Ed 1
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List ................................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement .............................................................................. 8
China RoHS Requirements (CN) .................................................... 9
China RoHS Requirement (EN) ................................................... 10
Chapter 1 - Product Specifications 13
1.1 Specifications ............................................................... 15
17
Chapter 2 – Hardware Information 17
2.1 Jumpers and Connectors ............................................. 18
2.2.1 IO Connector Information ............................................. 22
2.2.2 DC_IN (DC In Jack 4 Pin Din) ......................................... 23
2.2.3 DC_IN2 (ATX 1x4 Pin Power Connector) ...................... 24
2.2.4 CPU Socket (LGA 1200 Socket) .................................... 25
2.2.5 BKL_CN (Back Light Brightness Control Connector) .... 26
2.2.6 EDP (Embedded Display Port connector) ..................... 27
2.2.7 LSW (LVDS Resolution Jumper) ..................................... 28
2.2.8 Battery (Battery Connector) ......................................... 29
2.2.9 LVDS (LVDS Connector) ............................................... 30
