32
www.gigaipc.com
2.2.11 SPKR (Speaker Out Connector)
19
Speaker Out Connector
1
Pin No. Definition
1 SPEAKER L+
2 SPEAKER L-
3 SPEAKER R-
4 SPEAKER R+
Pin 1
