Mini-ITX Motherboard
mITX
-Q47EA (MQ47EAI-SI)
2.
2.18
GP
IO_CNT (
GPIO Connector
)
26
Pin 1
GPIO Connector
Pin No.
Definition
1
GPIO-
output
_1
2
GPIO
-inpu
t_1
3
GP
IO
-
output
_
2
4
GPIO-
input
_
2
5
GP
IO
-
output
_
3
6
GPIO-
input
_
3
7
GPIO-
output
_4
8
GPIO-
input
_
4
9
SMBus Clo
ck
10
SMBus DA
T
A
11
5V
12
GND
38
40
