2.2.21 SATA2, 3, 4 (SATA 6 Gb/s Connector x 3)
29
SATA 2
SATA 4
SATA 3
SATA 6GB/S Connector
7
1
7
1
SATA 3SATA 2
SATA 4
Pin No. Definition
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
