Mini-ITX Motherboard mITX-Q47EA (MQ47EAI-SI)
2.2.20 SATA_PWR (SATA Power Connector x 2)
28
SATA Power Connector Pin No. Definition
1 12V
2 GND
3 GND
4 5V
Pin 1
