GIGAIPC mITX-Q47EA User Manual

16
www.gigaipc.com
Motherboard mITX-Q47EA (MQ47EAI-SI)
Internal I/O
1 x 4-pin ATX main power connector
3 x SATA 6Gb/s connectors
2 x SATA power connectors
1 x CPU fan header
1 x System fan header
1 x Front panel header
1 x Front panel audio header
1 x 2W Speaker out header
4 x USB 2.0/1.1 headers
2 x USB 3.2 Gen1x1 headers
1 x COM header (RS-232)
1 x Clear CMOS jumper
1 x GPIO (8 bits) & SMBUS header
1 x Backlight Control header
1 x eDP connector
1 x PSU on header (Support ATX PSU PSU_ON)
1 x LVDS connector
1 x AT/ATX mode select jumer
Rear I/O
2 x Audio jacks (Line out, Mic in)
1 x COM (RS-232/422/485 and RI/5V/12V)
1 x HDMI
1 x Display Port
1 x D-Sub
2 x RJ45
3 x USB 3.2 Gen1x1 type A (Blue)
1 x USB 3.2 Gen2x1 type A (Red)
1 x DC Jack (+12V/+19V~+24VDC)
TPM 1 x TPM Header (LPC)
OS Compability Windows® 10 (x64)
PSU Connectors
1 x DC-in (+12V/+19V~+24VDC)
1 x 4-pin ATX power connector
Operang Properes
Operang temperature: 0°C to 60°C
Operang humidity: 0-90% (non-condensing)
Non-operang temperature: -40°C to 85°C
Non-operang humidity: 0%-95% (non-condensing)
Order Informaon Motherboard: 9MQ47EAINR-SI
Oponal kit:
TPM 1.2 module: 9CMUFLNR-00
TPM 2.0 module: 9CTM000NR-00
TPM Cable: 25CRZ-100600-S9R
