Upgrading to BRCM2.x
Figure 27: Front View of the BRCM2.x with Security Cover
Figure 28 and Figure 29 on page 30 show different configurations of a Security Cover.
Figure 28: Security Cover with Two Open Ports
Two Open Ports for use,
remaining ports covered
