MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019 Page 11
Passport EDGE Hardware Setup
The following templates are for a dual client setup using a customer display (8-Port):
41T-8- FRONT-EDGE-CD-BASIC-TRUNK
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 Switch (Trunk) Out To another switch
42T-8-FRONT-EDGE-CD-BASIC-2
ND
SWITCH
Port V-LAN Segment Device
1 Switch (Trunk) IN From front/another switch
2 Auxiliary Tablet 2
3 PayDev PIN Pad 2
4 Auxiliary Receipt Printer 2
5 Auxiliary Customer Display 2
6 Not Used Not Used
7 Auxiliary Applause
8 PayDev Dispensers
43T-8-FRONT-EDGE-CD-PAYMENT-TRUNK
Port V-LAN Segment DEVICE
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 Switch (Trunk) Out To another switch
44T-8-FRONT-EDGE-CD-PAYMENT-TRUNK-2
nd
SWITCH
Port V-LAN Segment Device
1 Switch (Trunk) IN From front/another switch
2 Auxiliary Tablet 2
3 PayDev PIN Pad 2
4 Auxiliary Receipt Printer 2
5 Auxiliary Customer Display 2
6 PaymentZone Payment
7 Auxiliary Applause
8 PayDev Dispensers
To Next Page
