Page 12 MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019
Passport EDGE Hardware Setup
The following templates are for a dual client setup using a customer display (16-Port):
45T-16-FRONT-EDGE-CD-BASIC
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 POS PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 Not Used Not Used
9 Auxiliary Tablet 2
10 PayDev PIN Pad 2
11 Auxiliary Receipt Printer 2
12 Auxiliary Customer Display 2
13 Auxiliary Applause
14 PayDev Dispensers
15 Not Used Not Used
16 Not Used Not Used
46T-16-FRONT-EDGE-CD-PAYMENT
Port V-LAN Segment Device
1 Switch (Trunk) In MG
2 EDH EDH
3 POS TPOS (Sever)
4 Auxiliary Tablet 1
5 PayDev PIN PAD 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 PaymentZone Payment
9 Auxiliary Tablet 2
10 PayDev PIN Pad 2
11 Auxiliary Receipt Printer 2
12 Auxiliary Customer Display 2
13 Auxiliary Applause
14 PayDev Dispensers
15 Not Used Not Used
16 Not Used Not Used
